- Our Most Popular Hinge Series for 1/4″ to 5/16″ (6 to 8 mm) Thick Glass
- Wall Mount Full Back Plate Standard Model(Factory Set for Standard Closing Position)
- Self-Centering with Reversible 5 Degree Pivot Pin
- Available in Several Beautiful Finishes
- Use Tempered Glass
Using two hinges with 1/4″ to 5/16″ glass (6 to 8 mm) the hinge will hold up to 62 lbs. (28 kg) with a maximum door width of 28″ (711 mm).
Using three hinges with 1/4″ to 5/16″ glass (6 to 8 mm) the hinge will hold up to 92 lbs. (42 kg) with a maximum door width of 32″ (813 mm).
Special Features: Most models offer a choice of Standard Model, factory set at standard closing position (0 degree), or 5 degree Pre-Set Model for tighter closure into shower interior. All models contain a Reversible 5 degree Pivot Pin. When activated, it allows 5 degree tighter door closure.
