- An Excellent Choice for Heavier, Wider Shower Doors
- Integrated Safety Interlock Enhances Glass Panel Control
- Wall Mount and 180 Degree Glass-to-Glass Models Available
- For Use with 3/8″ to 1/2″ (10 to 12 mm) Thick Tempered Glass
Plym Series Hinges have the ability of supporting wider, heavier doors, with a maximum door weight of 140 lbs. (64 kg), and a maximum door width of 39″ (1 m) using only two hinges.
Using two hinges with 3/8″ to 1/2″ glass (10 to 12 mm), 39″ (1 m) width, the two hinges will hold up to 140 lbs. (64 kg).
NOTE: Do not use three hinges.
