- Available in Both Flat and Radius Bases
- Stainless Steel or Zinc Alloy
- Includes Gaskets and Steel Pin for Optional Thru-Glass Installations
- Glass Cut-Out Required When Using Steel Pin Option
- Many Popular Finishes Available
SPECIFICATIONS:
Glass Thicknesses: For 1/4″ and 5/16″ (6 and 8 mm); For 3/8” (10 mm); For 1/2″ (12 mm)
Base Design: Flat.
For Use With: Square Tubing or Other Flat Surfaces.
Material: Choice of Zinc Constructed or Stainless Steel. Stainless Steel or Powder Painted Zinc Clamps are recommended for more durability in exterior applications.
Glass Fabrication:
For 1/4″ (6 mm), 5/16″ (8 mm), and 3/8″ (10 mm) Thick Glass: 1/2″ (12 mm) diameter hole required if using provided steel pin for glass support.
For 1/2″ (12 mm) Thick Glass: 9/16″ (14 mm) diameter hole required if using provided steel pin for glass support.
